601100
Maximum pressure(bar / psi): 241 / 3500
Rated flow (L/min / gpm): 19 / 5
Cavity: VC08-2
12 and 24 volt coils standard
Optional waterproof E-Coils rated up to IP69K
Industry common cavity ·Hardened parts for long life
| Maximum pressure | 241 bar (3500 psi) |
| Rated flow | 19 L/min (5 gpm) P = 7.8 bar (113.3 psi) ±10%, cartridge only, ① to ② coil energized |
| Maximum pilot flow | 0.76 L/min (0.2 gpm) |
| Relief pressure range from zero to maximum control current | Minimum Pressure is factory adjusted; A: 207~4.1 bar (3000~60 psi) |
| Hysteresis | ＜ 3% |
| Cavity | VC08-2 (See technical reference) |
| Fluid | Mineral-based or synthetics with lubricating properties |
| Viscosity range | 7.4 to 420 mm2/s |
| Temperature range | -40 to 100 ℃ (Buna N seals) |
| -54 to 107 ℃ (Polyurethane seals） | |
| -26 to 204 ℃ (Fluorocarbon seals) | |
| Degree of fluid contamination | The minimum pollution level is ISO4406 level 18/16/13, and level 15/13/11 is recommended to prolong the service life |
| Installation recommendation | When possible, the valve should be mounted below the reservoir oil level.This will maintain oil in the armature preventing trapped air instability. If this is not feasible, mount the valve horizontally for best results. |
