601100
Rated pressure (bar / psi) : 350 / 5000
Rated flow (L/min / gpm) : 30 / 7.9
Standard
Internal oil drain
Pilot control
Compact
High reliability ·More durable
| Rated pressure | 350 bar (5000 psi) |
| Rated flow | 30 L/min(7.9 gpm) |
| Adjustment pressure range | 70-350 bar |
| Pilot ratio | 2.5:1；5:1；10:1 |
| Internal leakage | ≤ 5 drops/min @ 80% of pressure setting |
| Cavity | T-11A (See technical reference) |
| Fluid | Mineral-based or synthetics with lubricating properties |
| Viscosity range | 7.4 to 420 mm2/s |
| Temperature range | -40 to 100 ℃ (Buna N seals) |
| Degree of fluid contamination | The minimum pollution level is ISO4406 level 18/16/13, and level 15/13/11 is recommended to prolong the service life |
