601100
Drift diameter: 10/12/15
Rated pressure (bar / psi) : 420
Rated flow (L/min / gpm) : 50/120/150
Compact design, stable and reliable
Fast response, shock resistant
Conforms to ISO 8643 standard
Enhanced system safety
| Rated pressure | 420 bar (6000 psi) | |
| Rated flow | 10E | 50 L/min (13 gpm) |
| 12E | 120 L/min (31 gpm) | |
| 15E | 150 L/min (39 gpm) | |
| Pressure adjustment range of relief valve | 150 ~ 420 bar | |
| Pilot opening pressureadjustment range | 10E/12E | 3 ~ 15 bar |
| 15E | 7 ~ 20 bar | |
| Weight | 10E: 2.0 kg；12E: 2.6 kg；15E: 3.8 kg | |
| Fluid | Mineral-based or synthetics with lubricating properties | |
| Viscosity range | 7.4 to 420 mm2/s | |
| Temperature range | -40 to 100 ℃ (Buna N seals) | |
| -54 to 107 ℃ (Polyurethane seals） | ||
| -26 to 204 ℃ (Fluorocarbon seals) | ||
| Degree of fluid contamination | The minimum pollution level is ISO4406 level 20/18/14, and level 17/15/13 is recommended to prolong the service life | |
