601100
Rated pressure：207 bar
Peak flow：11.4 L/min
Cavity：VC08-4
• Coils rated for continuous duty
• Interchangeable plug-in voltages
• Optional IP69K waterproof E-coil
• High efficiency wet armature construction
• Hardened components for increased durability
| Rated pressure | 207 bar(3000 psi) | |
| Peak flow | 11.4 L/min (3 gpm) | |
| Fluid | Mineral-based or synthetics with lubricating properties | |
| Fluid temperature range ℃ | -54 to 107 ℃ (Polyurethane seals） | |
| -40 to 100 ℃ (Buna N seals) | ||
| -26 to 204 ℃ (Fluorocarbon seals) | ||
| Viscosity range | 7.4 to 420 mm2/s | |
| Degree of contamination | The minimum pollution level is ISO4406 level 20/18/14, and level 17/15/13 is recommended to prolong the service life | |
| Internal Leakage | ≤ 164 mL/min@207bar | |
| Cavity | VC08-4 | |
| Coil Duty Rating | Continuous from 85% to 115% of nominal voltage | |
| Initial Coil Current Draw at 20℃ | E-Coil | 1.4A at 12VDC; 0.7A at 24VDC |
| D-Coil | 1.2A at 12VDC; 0.6A at 24VDC | |
| Minimum pull-in voltage | 85% of nominal at 207 bar | |
