601100
Path: 5, 10, 16
Pressure: up to 315 bar
Flow: up to 160 L/min
For subplates see catalogue
External closing of the pressure compensator, optional
Rotary knob with scale, optional lockable
| Fluid | Mineral oil ;Phosphate ester | ||||||||||||||
| Fluid temperature range | ℃ | -20~+80 | |||||||||||||
| Viscosity range | mm2/s | 10~800 | |||||||||||||
| Degree of contamination | Maximum permissible degree of fluid contamination: Class 9. NAS 1638 or 20/18/15, ISO4406 | ||||||||||||||
| Item Size | mm | 5 | 10 | 16 | |||||||||||
| Max. flow-rate | L/min | 0.2 | 0.6 | 1.2 | 3 | 6 | 10 | 15 | 10 | 16 | 25 | 50 | 60 | 100 | 160 |
| Pressure differential when backward flow B to A | bar | 0.5 | 0.5 | 0.6 | 0.9 | 1.8 | 3.6 | 6.7 | 2 | 2.5 | 3.5 | 6 | 2.8 | 4.3 | 7.3 |
| Flow stability range (-20℃ ~+80 ℃ )%Qmax | ±5 | ±3 | ±2 | ±2 | |||||||||||
| ±2( P= 210bar) | ±2( P= 315bar) | ||||||||||||||
| Working pressure | bar | 210 | 315 | ||||||||||||
| Min. pressure differential | bar | 3~5 | 6~8 | 3~7 | 5~12 | ||||||||||
| Weight | kg | 1.6 | 3.4 | 7.4 | |||||||||||
