601100
Rated pressure：345 bar
Peak flow：11 L/min
Cavity：VC08-4
• Coils rated for continuous duty
• Interchangeable plug-in voltages
• Optional IP69K waterproof E-coil
• High efficiency wet armature construction
• Hardened components for increased durability
| Rated pressure | 345 bar（5000 psi） | |
| Peak flow | See performance chart | |
| Fluid | Mineral-based or synthetics with lubricating properties | |
| Fluid temperature range ℃ | -54 to 107 ℃ (Polyurethane seals） | |
| -40 to 100 ℃ (Buna N seals) | ||
| -26 to 204 ℃ (Fluorocarbon seals) | ||
| Viscosity range | 7.4 to 420 mm2/s | |
| Degree of contamination | The minimum pollution level is ISO4406 level 18/16/13, and level 15/13/11 is recommended to prolong the service life | |
| Internal Leakage | ≤ 180 mL/min@345bar | |
| Cavity | VC08-4 | |
| Coil Duty Rating | Continuous from 85% to 115% of nominal voltage | |
| Initial Coil Current Draw at 20℃ | E-coil | 1.7A at 12VDC; 0.85A at 24VDC |
| D-coil | 1.67A at 12VDC; 0.83A at 24VDC | |
| Minimum pull-in voltage | 85% of nominal at 345 bar (3000 psi) | |
