601100
Rated pressure：207 bar
Peak flow：9.5 L/min
Cavity：VC08-2
• Continuous-duty rated coil
• Both ports may be fully pressurized
• Efficient wet-armature construction
• Cartridges are voltage interchangeable
• Optional waterproof E-Coils rated up to IP69K
• Industry common cavity
• Hardened parts for long life and low leakage
| Rated pressure | 207 bar(3000 psi) | |
| Peak flow | 9.5 L/min (2.5 gpm) | |
| Internal Leakage | ≤ 82 mL/min @207 bar | |
| Coil Duty Rating | Continuous from 85% to 115% of nominal voltage | |
| Initial Coil Current Draw at 20℃ | E-Coil | 1.4A at 12VDC; 0.7A at 24VDC |
| D-Coil | 1.2A at 12VDC; 0.6A at 24VDC | |
| Minimum pull-in voltage | 85% of nominal at 207 bar (3000 psi) | |
| Cavity | VC08-2 | |
| Fluid | Mineral-based or synthetics with lubricating properties | |
| Fluid temperature range ℃ | -54 to 107 ℃ (Polyurethane seals) | |
| -40 to 100 ℃ (Buna N seals) | ||
| -26 to 204 ℃ (Fluorocarbon seals) | ||
| Viscosity range | 7.4 to 420 mm2/s | |
| Degree of contamination | The minimum pollution level is ISO4406 level 20/18/14, and level 17/15/13 is recommended to prolong the service life | |
